Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | VMIVME‑7700‑111000 |
| Product Type | VMEbus Single‑Board Computer (SBC) |
| Series | GE / VMIC VMIVME‑7700 |
| Processor | Intel® Ultra Low Voltage Celeron® (400 MHz or 650 MHz) |
| Memory | Up to 512 MB SDRAM; optional bootable flash up to ~1 GB |
| Backplane | VMEbus compliant (VME64 modes) |
| Expansion | One PMC expansion site (PCI mezzanine) |
| Timers | Two 16‑bit and two 32‑bit programmable timers |
| Communication | Ethernet, USB, serial (via front panel) supported |
| Graphics | Optional SVGA support (on some variants) |
| Operating Systems | Supports embedded OSes (Linux, VxWorks, etc.) |
| Operating Temp. | Typical industrial range (often –40 °C to +85 °C) |
| Dimensions | Approx. VME 6U form factor (≈ 233 mm × 160 mm) |
| Weight | Approx. 0.4 kg (400 g) |
| Typical Applications | Embedded control, data acquisition, industrial automation |
FAQ
FAQ
Q1. What type of module is the VMIVME‑7700‑111000?
It is a VMEbus single‑board computer (SBC) used in industrial and embedded control systems.
Q2. Which processor family does it use?
It uses an Intel® Ultra Low Voltage Celeron® processor (400 MHz/650 MHz options).
Q3. How much memory does it support?
It typically has up to 512 MB of SDRAM and optional bootable flash memory.
Q4. What bus standard does it conform to?
It conforms to the VMEbus standard with support for VME64 modes.
Q5. Does it offer expansion capability?
Yes, it includes a PMC expansion site for additional I/O or functionality.
Q6. What interfaces can be accessed?
It supports Ethernet, USB, and serial interfaces on applicable front panels.
Q7. What is the physical size of the board?
The board follows a 6U VME form factor (~233 mm × 160 mm).
Q8. How much does it weigh?
The weighs about 0.4 kg (400 g).
