Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 621-6300 |
| Product Type | Source Output Module |
| System | Honeywell IPC 620 Programmable Controller System |
| Output Type | Source-type digital output |
| Number of Channels | Typically 8 or 16 (refer to rack configuration) |
| Operating Voltage | Nominal +24 VDC |
| Output Current | 0.5 A per point (typical, dependent on rack design) |
| Output Protection | Short-circuit protection and over-temperature shutdown |
| Mounting Type | Plug-in module for IPC 620 I/O rack |
| Interface | Connected to parallel I/O via PIOM (Parallel I/O Module) |
| Communication Protocol | Internal to rack, part of system bus |
| Dimensions (W x H x D) | 118 x 47 x 94 mm |
| Weight | 0.49 kg |
FAQ
FAQ
Q1: What control system is the 621-6300 module designed for?
A1: It is designed for the Honeywell IPC 620 Programmable Controller System for digital output applications.
Q2: Is the 621-6300 a source or sink output module?
A2: It is a source output module, which sources current to the load.
Q3: What is the maximum current per output channel?
A3: The typical maximum output current per channel is 0.5 A, depending on the system configuration.
Q4: Does the module provide output protection?
A4: Yes, it features short-circuit protection and automatic shutdown in case of over-temperature.
Q5: How is the module connected to the controller system?
A5: It is plugged into the IPC 620 I/O rack and communicates via the PIOM (Parallel I/O Module).
Q6: Is hot swapping supported?
A6: No, hot swapping is not supported. Power must be turned off before removal or installation.
Q7: What are the dimensions and weight of the module?
A7: The module measures 118 x 47 x 94 mm and weighs 0.49 kg.
Q8: What applications is this module suitable for?
A8: It is suitable for factory automation, discrete manufacturing, and industrial process control applications.
