Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 621-6350 |
| Product Type | Output Module for IPC 620 System |
| System Compatibility | IPC 620 Programmable Controller System |
| Output Type | Digital Output |
| Channels | 8 or 16 points (depending on configuration) |
| Operating Voltage | Typically 24 VDC |
| Output Current Capacity | Approx. 0.5 A per channel (check exact spec) |
| Isolation | Optical isolation per channel |
| Mounting Type | Installed in 621 I/O rack |
| Terminal Block Type | Swing-arm or screw terminal (depending on I/O rack setup) |
| Communication | Through PIOM (Parallel I/O Module) |
| Diagnostics | Status LEDs for channel indication |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 118 x 47 x 94 mm |
| Weight | 0.25 kg |
FAQ
FAQ
Q1: What type of output does the 621-6350 module provide?
A1: The 621-6350 provides digital output, typically used for controlling external relays, indicators, or actuators.
Q2: Is the 621-6350 module hot-swappable?
A2: No, it is not hot-swappable. Power must be turned off before insertion or removal to prevent damage.
Q3: How many output channels are available on the module?
A3: It typically supports 8 or 16 digital output channels depending on configuration.
Q4: What is the maximum current rating per output channel?
A4: Each channel can handle approximately 0.5 A. Exact ratings depend on the load and specifications.
Q5: Is the module electrically isolated?
A5: Yes, the output channels are optically isolated to protect the system and external devices.
Q6: Can this module be used with any IPC 620 system processor?
A6: Yes, it is compatible with IPC 620 series processors when used in conjunction with appropriate PIOM modules.
Q7: What diagnostics features are available?
A7: The module includes channel-specific status LEDs for monitoring output activity and fault conditions.
Q8: What kind of terminal blocks does the 621-6350 use?
A8: It supports swing-arm or screw terminal blocks depending on the 621 I/O rack configuration.
