Technical Specifications
| Item | Specification |
|---|---|
| Model | 621-9935 |
| Type | Serial I/O Module |
| Communication Ports | RS-232 / RS-485 |
| Supported Protocols | Modbus RTU, Honeywell proprietary |
| Baud Rate | 1200 – 115200 bps |
| Number of Ports | 2 independent serial channels |
| Input Voltage | 5 VDC (rack supplied) |
| Electrical Isolation | Isolated between ports |
| Status Indicators | Power, Communication, Fault LEDs |
| Data Format Support | 7/8 data bits, 1/2 stop bits, parity optional |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Style | I/O rack slot installation |
| System Compatibility | Honeywell TPS / TDC 3000 control systems |
| Dimensions | 264 x 32 x 127 mm |
| Weight | 0.63 kg |
FAQ
FAQ
Q1: What communication protocols does the 621-9935 support?
It supports standard Modbus RTU and Honeywell proprietary serial protocols.
Q2: How many serial ports are available on the module?
The module provides 2 independent RS-232 or RS-485 serial ports.
Q3: Does it support automatic switching between RS-232 and RS-485?
No, switching must be done manually or by configuration.
Q4: Is electrical isolation provided between ports?
Yes, electrical isolation is provided between the two serial channels.
Q5: How is the module powered?
It is powered by the I/O rack system at 5 VDC.
Q6: Is redundancy supported?
The module itself does not provide redundancy but can be used in a redundant setup.
Q7: Which Honeywell systems is it compatible with?
Compatible with Honeywell TPS and TDC 3000 platforms.
Q8: What are its dimensions and weight?
Dimensions: 264 x 32 x 127 mm; Weight: approx. 0.63 kg.
