Technical Specifications
| Item | Specification |
|---|---|
| Model | 621-9936 |
| Type | Serial Link Module |
| Communication Ports | RS-232C / RS-485 |
| Supported Protocols | Honeywell proprietary (TPS systems) |
| Max Transmission Rate | 115.2 kbps |
| Serial Channels | 1 bidirectional serial communication channel |
| Input Voltage | 5 VDC (rack supplied) |
| Status Indicators | Comm, Fault, Activity LEDs |
| Connector Type | DB9 or terminal block (varies by config) |
| Electrical Isolation | Isolation between system logic and comm ports |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Method | Rack-mounted module |
| System Compatibility | Honeywell TDC 3000 / TPS |
| Dimensions | 154 x 32 x 127 mm |
| Weight | 0.66 kg |
FAQ
FAQ
Q1: What is the main function of the 621-9936 module?
It enables bidirectional serial communication between control systems and external serial devices.
Q2: What communication types are supported?
It supports RS-232C and RS-485 interfaces.
Q3: Does the module support Modbus?
No, it only supports Honeywell proprietary serial protocols.
Q4: Are there status indicators on the module?
Yes, there are LEDs for communication, fault, and activity.
Q5: How is the module powered?
It is powered by the I/O rack at 5 VDC.
Q6: Can it communicate with third-party devices?
Primarily designed for Honeywell systems, limited third-party integration is possible via protocol converters.
Q7: Is hot-swapping supported?
No, the module must be powered off before insertion or removal.
Q8: What are its dimensions and weight?
Dimensions: 154 x 32 x 127 mm; Weight: approx. 0.66 kg.
