Technical Specifications
| Parameter | Description |
|---|---|
| Model | 8C-TDIL11 |
| Input Channels | 32 digital inputs |
| Input Voltage | 18 VDC to 30 VDC |
| ON Sense Voltage/Current | ≥13 VDC or ≥3 mA |
| OFF Sense Voltage/Current | ≤5 VDC or ≤1.2 mA |
| Input Impedance | 4.2 kΩ |
| Isolation | Optical, 1000 VAC RMS |
| Isolation Type | Optical coupling |
| Power Supply | Supports internal or external excitation |
| Installation Type | Redundant, IOTA model: CC-TDIL61 (12 inches) |
| Input Delay | 5 ms ±20% |
| Field Resistance Range | ON: ≤300 Ω @ 15 VDC; OFF: ≥30 kΩ @ 30 VDC |
| Dimensions | 51 mm × 267 mm × 178 mm |
| Weight | 0.5 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many input channels does the 8C-TDIL11 support?
A1: The module supports 32 digital input channels.
Q2: What is the input voltage range?
A2: The input voltage range is 18 to 30 VDC.
Q3: Does the module have electrical isolation?
A3: Yes, it uses optical isolation rated at 1000 VAC RMS.
Q4: Is redundancy supported?
A4: Yes, it supports redundancy with the CC-TDIL61 IOTA module.
Q5: What is the typical input delay?
A5: The delay is 5 ms ±20%.
Q6: Does the module supply non-incendive field power?
A6: Yes, and it eliminates the need for separate marshalling power.
Q7: Does it support open wire detection?
A7: No, this model does not support open wire detection (unlike CC-PDIL01).
Q8: What are the typical applications?
A8: It is used for discrete signal acquisition in industrial automation, such as switch status monitoring and alarm indication.
