Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 900A01-0002 |
| Product Type | Analog Output Module |
| Outputs per Module | 4 (Isolated) |
| Output Range | 0 to 21.8 mA (user-scalable) |
| Load Resistance | Maximum 750 ohms |
| Galvanic Isolation | 500 VDC Channel to Channel, 600 VDC to Logic |
| Accuracy | ±0.1% full scale (under reference conditions) |
| Minimum Current Sensing | >3.5 mA per output |
| Calibration Data | Stored in non-volatile memory (Factory & Field calibration) |
| Output Verification | Yes, feedback to controller |
| D/A Resolution | 12 bits |
| Power Supply Loading (5V) | 40 mA max |
| Power Supply Loading (24V) | 200 mA max |
| Max Modules per Rack | 10 (up to 12 with de-rating) |
| Dimensions (H × W × D) | 137 × 35.6 × 137.16 mm |
| Weight | 0.21 kg |
FAQ
FAQ
Q1: How many analog outputs does the 900A01-0002 module support?
A1: The module provides 4 isolated analog current output channels.
Q2: What is the output current range of the module?
A2: Each output can be configured from 0 to 21.8 mA and scaled by the user as needed.
Q3: Are the output channels galvanically isolated?
A3: Yes, each output is isolated from the others (500 VDC) and from logic circuits (600 VDC).
Q4: Does the module support a failsafe value?
A4: Yes, a user-specified failsafe output value can be configured for loss of communication conditions.
Q5: Is output feedback supported?
A5: Yes, the module provides feedback to the controller indicating that current is flowing.
Q6: How is calibration managed for this module?
A6: Calibration data is stored in non-volatile memory; the module supports both redundant factory calibration and per-channel field calibration.
Q7: What is the maximum allowable load resistance per output?
A7: Each output can drive a load of up to 750 ohms.
Q8: How many of these modules can be installed in a single I/O rack?
A8: Up to 10 modules can be installed, or 12 with ambient temperature de-rating.
