Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 900G01-0102 |
| Module Type | Digital Input Module – Contact Closure Type |
| Input Channels | 16 (single-ended) |
| Voltage Supply | 15 VDC nominal (supplied by controller) |
| Switching Current | 2.6 mA nominal |
| Maximum Contact Resistance | 1000 ohms |
| Response Time (OFF to ON) | ≤ 4 ms |
| Response Time (ON to OFF) | ≤ 6 ms |
| Galvanic Isolation | Between field wiring and module logic |
| Status Indicators | Per-channel green LED for ON state; module LEDs for scan/force/fault |
| Power Consumption (5V) | 130 mA max |
| Power Consumption (24V) | 40 mA max |
| Dimensions (H x W x D) | 137 x 35.6 x 151.7 mm |
| Weight | 0.354 kg |
FAQ
FAQ
Q1: How many input channels does the module support?
A1: The 900G01-0102 module supports 16 single-ended contact input channels.
Q2: What is the voltage provided for the input circuit?
A2: The module supplies 15 VDC nominal to external switching circuits.
Q3: What is the nominal switching current per input?
A3: Each input typically draws 2.6 mA when closed.
Q4: What is the maximum contact resistance allowed?
A4: The maximum contact resistance is 1000 ohms.
Q5: Can the module be hot-swapped?
A5: Yes, it supports removal and insertion under power, but field wiring must be disconnected first.
Q6: What is the response time for input changes?
A6: OFF to ON is ≤ 4 ms, and ON to OFF is ≤ 6 ms.
Q7: Are there individual status indicators for each channel?
A7: Yes, each channel has a green LED to indicate its ON state.
Q8: How is the module mounted?
A8: It mounts on a standard 35mm DIN rail.
