Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Honeywell 900P01-0101 |
| Type | ControlEdge HC900 Power Supply Module |
| Input Voltage Range | 100–240 VAC (50/60 Hz), single phase |
| Output Voltage | 24 VDC |
| Output Power | 58 W (typical) |
| Output Current | 2.4 A (maximum) |
| Efficiency | > 80% |
| Inrush Current | < 30 A @ 230 VAC |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% RH non-condensing |
| Mounting | DIN rail or panel mounted |
| Cooling Method | Natural convection |
| Protection | Overvoltage, overload, short circuit |
| Dimensions (W x H x D) | 137 x 72.6 x 151.7 mm |
| Weight | 0.82 kg |
FAQ
FAQ
Q1: What input voltage range is supported by this power supply module?
A1: It supports a wide input range of 100 to 240 VAC, 50/60 Hz.
Q2: What are the output power and current ratings?
A2: The output power is 58 watts with a maximum output current of 2.4 amps.
Q3: Does it have overload protection?
A3: Yes, it includes built-in protection for overvoltage, overload, and short circuit.
Q4: What installation methods are available?
A4: It can be mounted on a DIN rail or a panel.
Q5: Is active cooling required?
A5: No, it uses natural convection for cooling.
Q6: What is the operating temperature range?
A6: The operating temperature range is from 0°C to 60°C.
Q7: Does the power module retain configurations after a power loss?
A7: The power supply does not store configurations; configurations are held in the controller.
Q8: Can this module be used in a redundant system?
A8: Yes, it supports redundant power supply configurations for high availability systems.
