Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 900RR0-0101 |
| Product Type | Redundant CPM Rack |
| Dimensions (H x W x D) | 137 mm x 261.6 mm x 151.7 mm |
| Weight | 1.751 kg |
| Rack Material | Polyvinyl Chloride (PVC), UL94-V0 |
| Mounting | DIN rail 35 mm wide |
| Environment | G3 Harsh Environment Conformal Coating |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH non-condensing |
| Storage Humidity | 5% to 95% RH non-condensing |
| Certifications | CE, UL, ATEX, UKCA, IECEx, CSA, FM |
| Vibration Resistance | 5–15.77Hz at 2.03mm; 15.77–250Hz at 1.0g |
| Installation Category | Category II, Pollution Degree 2 |
| ROHS Compliance | Yes (except PSU) |
FAQ
FAQ
Q1: What is the primary function of the Honeywell 900RR0-0101?
A1: It supports redundant Control Processing Modules (CPMs) in the HC900 system, providing high system availability and fault tolerance.
Q2: What type of mounting does the rack support?
A2: It supports 35mm DIN rail mounting for convenient integration into control enclosures.
Q3: What is the operating temperature range for the 900RR0-0101?
A3: It operates from 0°C to 60°C and can be stored between -40°C and 70°C.
Q4: Is the product certified for industrial safety standards?
A4: Yes, it complies with CE, UL, ATEX, UKCA, IECEx, CSA, and FM certifications.
Q5: Does the 900RR0-0101 have vibration resistance?
A5: Yes, it withstands vibrations of 2.03mm at 5–15.77Hz and 1.0g at 15.77–250Hz.
Q6: Is there protection against harsh environments?
A6: Yes, all modules (except PSU) have G3-level conformal coating for corrosion resistance.
Q7: Can this rack be used with different power supplies?
A7: Yes, it is compatible with Honeywell 900P01 and 900P24 power supply modules.
Q8: What are the dimensions and weight of the 900RR0-0101?
A8: The dimensions are 137 x 261.6 x 151.7 mm, and the weight is 1.751 kg.
