Honeywell CC-PAIH02 51405038-375 C300 Hart Analog Input Module

FAQ (Q&A Format)

Q1: What is the main function of the CC-PAIH02 module?
A1: The CC-PAIH02 functions as a 16-channel high-level analog input module with HART protocol support, designed for integration into Honeywell’s Series C systems.

Q2: Does the CC-PAIH02 module support differential inputs?
A2: Yes, the CC-PAIH02 supports differential inputs on all 16 channels, offering greater flexibility and noise immunity in analog signal acquisition.

Q3: Which systems or configurations is the CC-PAIH02 compatible with?
A3: It is compatible with Series C I/O systems, specifically supporting IOTAs such as CC-TAID01, CC-TAID11, Cx-TAIX01, and Cx-TAIX11 for both redundant and non-redundant configurations.

Q4: Is this module compatible with HART communication protocols?
A4: Yes, it supports HART protocol version 6.0 and above, with features like HART device variable mapping, device status, and configuration transfer.

Q5: What software version is required to operate the CC-PAIH02?
A5: It is supported on Experion PKS R410 or later. Older firmware versions are not compatible and may result in module malfunction.

Q6: Can this module be used in intrinsically safe environments?
A6: Yes, when used with suitable GI/IS IOTA models like Cx-GAIX11 or Cx-GAIX21, along with isolators such as MTL4541 or MTL4544.

Q7: What are the power and wiring requirements for installation?
A7: It draws power via the IOTA base and requires proper grounding. Wiring depends on the IOTA type and may require shielded cables for analog signals.

Q8: What distinguishes CC-PAIH02 from its predecessor CC-PAIH01?
A8: CC-PAIH02 offers differential input capability across all 16 channels and full HART integration, while CC-PAIH01 supports differential inputs only on selected channels.
