Manufacturer：Honeywell
Product Number：FC-TSRO-08UNI
Product Type：Field Termination Assembly Module
Origin：USA
Dimensions：274 × 109 × 71 mm
Weight：0.85 kg
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of outputs does the FC-TSRO-08UNI support?
A1: The module provides 8 relay-based safe output channels, each capable of switching AC or DC loads up to 250 VAC or 250 VDC at a maximum of 2 A.
Q2: Is the FC-TSRO-08UNI suitable for SIL3 safety applications?
A2: Yes, it is certified for use in safety-critical applications up to SIL3 according to IEC 61508.
Q3: What is the purpose of the conformal coating in the FC-type variant?
A3: The conformal coating provides additional protection against humidity, dust, and other environmental contaminants, ensuring higher reliability in harsh environments.
Q4: How are the relays protected in this module?
A4: Each channel includes a fused NO field contact rated at 2 AT (slow-acting) for overcurrent protection.
Q5: Can this module be mounted on standard DIN rails?
A5: Yes, it supports mounting on both TS32 and TS35 × 7.5 DIN rails using a universal snap-in mechanism.
Q6: What is the expected electrical life of the relays?
A6: The electrical life depends on the switched load but is typically in the range of hundreds of thousands of operations under rated conditions.
Q7: What type of terminal connections does the module support?
A7: The module features screw terminals for both signal (2.5 mm² max) and power (16 mm² max) wiring, with specified strip lengths and tightening torques.
Q8: Is external power required for operation of the FC-TSRO-08UNI module?
A8: Yes, a common external power supply is connected via screw terminals, shared across all channels.
