Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Single-node Card |
| Model | MUS28-100 51195458-300 |
| Function | Provides single-node communication interface for control systems |
| Communication Protocol | Honeywell proprietary single-node communication protocol |
| Power Supply Voltage | 24 V DC (±10%) |
| Power Consumption | Approximately 5 W |
| Interface Type | Backplane connection |
| Data Transmission Rate | Up to 1 Mbps |
| Isolation | Optical and galvanic isolation between field and system |
| LED Indicators | Communication status, power, and fault indicators |
| Diagnostic Functions | Communication error and hardware fault detection |
| Mounting Method | Mounted on Honeywell control rack |
| Dimensions | 160 x 120 x 30 mm |
| Weight | 0.35 kg |
| Operating Temperature | 0 to 55°C |
| Storage Temperature | -25 to 70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Cooling Method | Natural air circulation |
FAQ
FAQ
Q1: What is the function of the MUS28-100 51195458-300 Single-node Card?
It provides a single-node communication interface that connects field devices to Honeywell control systems.
Q2: What is the operating voltage for this module?
The module operates at 24 V DC (±10%).
Q3: What is the communication rate supported?
It supports data transmission rates up to 1 Mbps.
Q4: Does the module provide electrical isolation?
Yes, it features optical and galvanic isolation between the field and system sides.
Q5: How is the module mounted?
It is mounted directly on the Honeywell control rack backplane.
Q6: Does it include diagnostic features?
Yes, it can detect communication and hardware faults for maintenance and monitoring.
Q7: What are the dimensions and weight of the module?
The module measures 160 x 120 x 30 mm and weighs approximately 0.35 kg.
Q8: What is the typical operating temperature range?
The operating temperature range is 0 to 55°C.
