Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | Honeywell RM7888A1019 |
| Series | 7800 Series |
| Type | Microprocessor-based Burner Control Relay Module |
| Input Voltage | 120 Vac (+10% / -15%), 50/60 Hz (±10%) |
| Power Dissipation | RM7888A: Max. 10 W |
| Max Connected Load | 2000 VA |
| Ambient Operating Temperature | -40 °C to +60 °C |
| Ambient Storage Temperature | -40 °C to +66 °C |
| Relative Humidity | 0–85% RH, non-condensing |
| Vibration | Max. 0.5G continuous |
| Electrical Fusing | Max. 20A (type FRN or equivalent) |
| Display Compatibility | Optional Keyboard Display Module S7800A1001 |
| Communication Options | Modbus (S7810M1003), DATA CONTROLBUS™ (S7810A1009) |
| Safety Certification | SIL3 capable in suitable SIS configuration |
| Mounting Options | Q7800A1005 (panel), Q7800B1003/B1011 (wall/burner) |
| Dimensions | 127 mm × 127 mm × 133 mm |
| Weight | 0.83 kg |
FAQ
FAQ
Q1: What is the main function of the RM7888A1019 module?
A1: The RM7888A1019 is a burner control relay module that provides automatic startup sequencing, flame supervision, safety diagnostics, system status indication, and historical fault recording.
Q2: What fuel types is this module compatible with?
A2: It is designed for use with gas, oil, coal, or combination fuel industrial burner systems.
Q3: Does the module support communication functions?
A3: Yes, it supports communication via optional Modbus and DATA CONTROLBUS™ modules.
Q4: Is the RM7888A SIL certified?
A4: Yes, it is SIL3 capable when used within a properly designed Safety Instrumented System.
Q5: What accessories are required for operation?
A5: A plug-in flame signal amplifier and subbase are required; optional accessories include a keyboard display module, remote reset module, etc.
Q6: Are there specific mounting directions for the module?
A6: Vertical mounting is recommended. Horizontal mounting with terminals pointing downward may reduce the maximum ambient temperature rating.
Q7: What are the power supply requirements?
A7: The operating voltage is 120 Vac ±10% at 50/60 Hz ±10%.
Q8: What diagnostic capabilities are included?
A8: Features include first-out annunciation, dynamic input checks, flame signal monitoring, self-diagnostics, and fault history logging.
