Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | TC-CCR013 |
| Order Number | 51199942-300 |
| Interface Type | ControlNet, redundant communication interface |
| Applicable System | Honeywell C300 Controller |
| Installation Type | Rack-mounted module |
| Communication Rate | 5 Mbps |
| Redundancy Support | Supported |
| Supported Protocol | ControlNet |
| Power Supply | Supplied by system chassis |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | 100 x 50 x 25 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What is the main function of the TC-CCR013 module?
A1: It serves as a ControlNet communication interface module, enabling redundant communication for high system reliability and data integrity.
Q2: Does the TC-CCR013 support redundancy?
A2: Yes, it supports redundant communication configurations for ControlNet networks.
Q3: Which Honeywell systems is this module compatible with?
A3: It is primarily used with Honeywell C300 systems for communication with I/O modules or controllers.
Q4: How is the module installed?
A4: It is a rack-mounted module designed to be inserted into standard Honeywell system chassis.
Q5: What communication protocol does it support?
A5: The module supports the ControlNet protocol, suitable for real-time industrial data transmission.
Q6: What is the operating temperature range?
A6: Operating range is 0°C to 60°C, and storage range is -40°C to 85°C.
Q7: What are the dimensions and weight of the module?
A7: The dimensions are 100 x 50 x 25 mm, and the weight is 0.2 kg.
Q8: Is an external power supply needed?
A8: No, it is powered by the system chassis and requires no separate power source.
