Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | T8311C |
| Manufacturer | ICS Triplex / Rockwell Automation |
| Product Series | Trusted® TMR |
| Product Type | Trusted TMR Expander Interface Module |
| Main Function | Interface between the Controller Chassis IMB and the Expander Bus |
| Architecture | Triple Modular Redundancy (TMR) |
| Bus Data Rate | 250 Mbps |
| Backplane Supply | 20–32 VDC |
| Field Power Supply | Not required |
| Power Consumption | Approx. 54 W |
| Maximum Expansion Distance | 30 m with TC-301 copper cable / up to 10 km with fiber converters |
| Chassis / Slot | Trusted T8100 Controller Chassis / I/O module slot |
| Isolation | 50 V basic insulation |
| Hot Replacement | Supported |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 10–95%, non-condensing |
| Dimensions (H × W × D) | 266 × 31 × 303 mm |
| Product Weight | Approx. 1.14 kg |
| Safety Architecture | HIFT TMR |
| Typical Application | Safety Instrumented Systems, ESD and critical process control |
FAQ
FAQ
Q1: What is the T8311C used for?
A: It is used to connect the Trusted Controller Chassis with Trusted Expander Chassis, providing communication between the IMB and Expander Bus.
Q2: What communication speed does the T8311C support?
A: The Trusted Expander Bus operates at 250 Mbps.
Q3: What is the input power requirement?
A: The module receives 20–32 VDC through the Trusted backplane and does not require a separate field power supply.
Q4: How far can the T8311C communicate?
A: With TC-301 copper cable, the maximum distance is approximately 30 m. With the appropriate fiber converters, the distance can reach approximately 10 km.
Q5: Does the T8311C use TMR architecture?
A: Yes. It uses a Triple Modular Redundant (TMR), hardware-implemented fault-tolerant architecture for high availability.
Q6: Can the T8311C be hot-swapped?
A: Yes. The Trusted architecture supports hot replacement of the module when the system is configured according to the applicable Trusted installation requirements.
Q7: What is the operating temperature range?
A: The current documentation specifies 0°C to +60°C, with a storage range of -25°C to +70°C.
Q8: What are the dimensions and weight of the T8311C?
A: The documented dimensions are 266 × 31 × 303 mm (H × W × D), and the weight is approximately 1.14 kg.
