Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 3604E |
| Module Type | Digital Output Module (24 VDC, Opto-Isolated, Non-Commoned, TMR) |
| Number of Output Points | 16 |
| Output Voltage | 24 VDC |
| Output Type | Discrete |
| Isolation | Optical isolation for each output |
| Redundancy | Triple Modular Redundant (TMR) with 2-out-of-3 voting |
| Diagnostic Features | Loopback detection, output voter diagnostics |
| Mounting | Installed in Tricon chassis slot |
| Hot Spare Capability | Yes |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 75°C (-40°F to 167°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 270 x 100 x 40 mm |
| Weight | 0.249 kg |
FAQ
FAQ
Q1: What type of redundancy does the 3604E module support?
A1: It supports Triple Modular Redundant (TMR) architecture with 2-out-of-3 voting logic.
Q2: Can the 3604E module operate as a hot spare?
A2: Yes, it can be configured as a hot spare for online repair and redundancy.
Q3: How many discrete outputs does the module provide?
A3: It provides 16 opto-isolated discrete output points.
Q4: What is the isolation method used in the 3604E module?
A4: Optical isolation is used for each individual output point.
Q5: Is loopback diagnostics supported on this module?
A5: Yes, loopback detection is supported for internal fault verification.
Q6: What is the intended output voltage range for the 3604E module?
A6: The module is designed for 24 VDC discrete output applications.
Q7: Can the module be replaced online without shutting down the system?
A7: Yes, it supports online replacement using hot spare functionality.
Q8: In which industrial applications is the 3604E typically used?
A8: It is used in safety-critical systems such as ESD, BMS, FGS, and turbine control.
