Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3604E |
| Module Type | Digital Output Module |
| Output Type | Opto-Isolated, Non-commoned |
| Number of Output Points | 16 |
| Output Voltage | 24 VDC |
| Output Isolation | Optical isolation for each output |
| Redundancy Architecture | Triple-Modular Redundant (TMR) |
| Diagnostic Capability | Loopback diagnostics and output voter diagnostics (OVD) |
| Hot-Spare Support | Yes, supports hot-spare module configuration |
| Output Drive Capability | 0.5 A per channel (maximum), resistive or inductive load |
| Response Time | < 1 ms (typical) |
| Power Consumption | 10 W (per module) |
| Communication | Communicates with Main Processor via triplicated I/O bus |
| Dimensions (W x H x D) | 270 x 100 x 40 mm |
| Weight | 0.249 kg |
FAQ
FAQ
Q1: What is the main function of the 3604E module?
A1: The 3604E is a digital output module designed for 24 VDC signals, featuring opto-isolated outputs and TMR fault tolerance.
Q2: How many output points does this module support?
A2: The module supports 16 opto-isolated, non-commoned digital output points.
Q3: Does the module support redundancy?
A3: Yes, it operates in a Triple-Modular Redundant (TMR) architecture and supports hot-spare module configuration.
Q4: Can the module drive inductive loads?
A4: Yes, each output can drive up to 0.5 A for resistive or inductive loads.
Q5: Is online module replacement supported?
A5: Yes, with hot-spare support, the module can be replaced online without interrupting system operation.
Q6: What is the typical response time of the module?
A6: The typical response time is less than 1 millisecond.
Q7: What are the dimensions and weight of the module?
A7: The module measures 270 x 100 x 40 mm and weighs approximately 0.249 kg.
Q8: Does the module include fault detection features?
A8: Yes, it includes loopback detection and Output Voter Diagnostics (OVD) for real-time fault identification and safety assurance.
