Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 3623 / 3623T |
| Module Type | Supervised Digital Output Module |
| Output Voltage Range | 120 VDC (nominal) |
| Output Type | Opto-Isolated, Commoned, Supervised |
| Number of Output Points | 16 |
| Output Drive Capability | 0.5 A per point (maximum) |
| Output Circuit Isolation | Optical isolation per point; channel-to-channel isolation |
| Diagnostic Features | Loopback detection, Output Voter Diagnostic (OVD), channel supervision |
| Redundancy Architecture | Triple-Modular Redundancy (TMR) |
| Compatibility | Tricon V9.6 and later |
| Dimensions | 115 mm × 230 mm × 50 mm |
| Weight | 1.5 kg |
FAQ
FAQ
Q1: How many digital output points does the module support?
A1: The Triconex 3623 module supports 16 digital output points.
Q2: Does the module provide output diagnostics?
A2: Yes, it features loopback detection, output voter diagnostics, and full output supervision.
Q3: What is the output voltage level?
A3: The module supports a nominal output of 120 VDC.
Q4: What is the maximum drive current per output point?
A4: Each output point can drive up to 0.5 A.
Q5: What redundancy architecture does the module use?
A5: It uses Triple-Modular Redundancy (TMR) architecture.
Q6: Which system versions is this module compatible with?
A6: It is compatible with Tricon systems version 9.6 and above.
Q7: What are the physical dimensions and weight of the module?
A7: The module measures 115 x 230 x 50 mm and weighs approximately 1.5 kg.
Q8: Is the module hot-swappable?
A8: Yes, it supports online hot-swapping and includes hot-spare capability for continuous operation.
