Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3625A |
| Module Type | Supervised/Non-Supervised Digital Output |
| Output Type | 24 VDC, Opto-Isolated, Commoned |
| Number of Output Channels | 32 |
| Output Current (per channel) | 0.5 A (max) |
| Output Voltage | 18–32 VDC |
| Load Type | Resistive or inductive |
| Diagnostic Features | Loopback test, output voter diagnostics |
| Channel Isolation | Channel-to-channel and field-to-system |
| Voting Logic | 2-out-of-3 voting for fault tolerance |
| Power Consumption | 10 Watts |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 75°C |
| Relative Humidity | 5%–95%, non-condensing |
| Vibration Resistance | 2 G @ 10–150 Hz (IEC 60068-2-6) |
| Shock Resistance | 15 G, 6–11 ms (IEC 60068-2-27) |
| Dimensions | 115 x 230 x 50 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: How many output channels does the 3625A module support?
A1: The 3625A module supports 32 digital output channels.
Q2: What is the maximum output current per channel?
A2: The maximum output current is 0.5 amps per channel.
Q3: What diagnostic features are included in the module?
A3: It includes loopback testing and Output Voter Diagnostics (OVD) for each point.
Q4: Does the module support hot-spare configuration?
A4: Yes, Triconex systems support hot-spare I/O modules for online replacement without process interruption.
Q5: What is the output type of this module?
A5: The output is a 24VDC digital signal, opto-isolated and commoned.
Q6: How does the module achieve fault tolerance?
A6: It uses a 2-out-of-3 voting architecture to ensure fault-tolerant operation.
Q7: Can the module drive inductive loads?
A7: Yes, it is capable of driving both inductive and resistive loads.
Q8: What are the installation requirements for the 3625A?
A8: The module must be installed in a logical slot within a Tricon chassis and can be configured with a hot-spare module for online repair.
