Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | Triconex 3625C |
| Type | Digital Output Module (Supervised/Non-Supervised) |
| Voltage | 24 VDC |
| Output Channels | 32 points |
| Channel Isolation | Yes, optically isolated per point |
| Output Type | Sourcing |
| Diagnostic Functions | Loopback test, output voter diagnostics |
| Output Drive Method | 2-out-of-3 voter logic with quadruplicated output drivers |
| Redundancy | Triple-Modular Redundant (TMR) |
| Supervision | Configurable supervision per point |
| Output Switching Device | Solid-state (opto-isolated) |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 75°C (-40 to 167°F) |
| Relative Humidity | 5% to 95% non-condensing |
| EMC Compliance | IEC 61000 standards, CE Mark |
| Dimensions | 22 x 408 x 400 mm |
| Weight | 2.06 kg |
FAQ
FAQ
Q1: How many output channels does the Triconex 3625C module support?
A1: It supports 32 discrete 24VDC output channels.
Q2: Does the module have output diagnostic features?
A2: Yes, it includes loopback detection and output voter diagnostics for each point.
Q3: Is redundancy supported by this module?
A3: Yes, it is based on Triple-Modular Redundant (TMR) architecture for high reliability.
Q4: Does the module offer supervision per output point?
A4: Yes, configurable supervision is available on each output channel.
Q5: Is the output sourcing or sinking type?
A5: The Triconex 3625C provides sourcing-type digital outputs.
Q6: Are the outputs driven by relays or solid-state devices?
A6: Solid-state devices with optical isolation are used for output switching.
Q7: Can the module be replaced online during operation?
A7: Yes, hot-spare and online replacement capabilities are supported.
Q8: What kind of termination panel is compatible with this module?
A8: It is compatible with standard Tricon external termination panels (ETPs) for field connections.
