Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell Analytics |
| Product Number | 05701-A-0441 |
| Product Type | Power Supply Subunit |
| Product Series | System 57 |
| Application | System 57 gas and fire detection systems |
| Primary Function | Power expansion for the 16-way System 57 power supply |
| Power Rating | 50 W |
| Upgrade Capacity | Enables the 16-way PSU to increase available power beyond 100 W |
| Input Voltage | 85–264 V AC, 47–440 Hz / 110–340 V DC |
| Output Voltage | 24 V DC nominal, ±10% |
| Power Supply Type | Switched-mode power supply |
| Overload Protection | Yes, automatic recovery |
| Overvoltage Protection | Yes |
| Mounting | 19-inch universal profile, 16-way System 57 PSU |
| Operating Temperature | -25 to +55°C |
| Operating Humidity | 20–90% RH, non-condensing |
| Earthing | M5 earth stud |
| Approval | EN 50270 |
| Subunit Weight | Approx. 0.815 kg |
| Dimensions | Approx. 482.6 × 44.5 × 250 mm* |
| Origin | USA |
FAQ
FAQ
Q1: What is the Honeywell 05701-A-0441 used for?
A: The 05701-A-0441 is a 50 W power supply subunit used to expand the power capacity of a Honeywell System 57 16-way power supply.
Q2: What is the power rating of the 05701-A-0441?
A: The subunit provides an additional 50 W of available power. It contains a 50 W switched-mode AC-to-DC power supply module as standard.
Q3: What input voltage does the 05701-A-0441 support?
A: The System 57 power-supply configuration operates from 85–264 V AC at 47–440 Hz, or 110–340 V DC.
Q4: What output voltage does the power supply provide?
A: The power supply provides a nominal 24 V DC output, with a tolerance of approximately ±10%.
Q5: Can the 05701-A-0441 increase the power capacity of a System 57 PSU?
A: Yes. It is specifically designed as an upgrade subunit for the 16-way PSU. A basic 16-way PSU can be expanded from 50 W to 100 W, and the additional subunit can provide another 50 W. With an additional 50 W module, the system can reach up to 200 W depending on configuration.
Q6: Does the 05701-A-0441 have overload protection?
A: Yes. The switched-mode power-supply modules are protected against overload and are designed to recover automatically after the overload condition is removed. Overvoltage protection is also provided.
Q7: What are the dimensions and weight of the 05701-A-0441?
A: The subunit itself weighs approximately 0.815 kg. Because it is installed inside the 16-way PSU enclosure, published dimensional information generally refers to the complete 1U, 19-inch PSU assembly, approximately 482.6 × 44.5 × 250 mm.
Q8: Which system is compatible with the 05701-A-0441?
A: The 05701-A-0441 is designed for the Honeywell System 57 and specifically serves as an upgrade component for the 16-way AC-to-DC power supply. Honeywell’s System 57 documentation lists the part number directly under the power-supply components.
