Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | 1C31110G01 |
| Module Type | Digital Input Module |
| Number of Channels | 32 channels |
| Input Type | Dry Contact Input |
| Voltage Level | 24 VDC |
| Input Current | Approx. 6 mA @ 24 VDC |
| Status Indicators | LED indicator per channel |
| Redundancy Support | Supported |
| Mounting | Plug-in module, Ovation backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (W x H x D) | 150 x 120 x 90 mm |
| Weight | 0.145 kg |
FAQ
FAQ
Q1: What type of input does the 1C31110G01 module support?
A1: It supports dry contact type digital inputs.
Q2: How many input channels are available per module?
A2: The module offers 32 digital input channels.
Q3: Does the module provide channel status indication?
A3: Yes, each channel has an LED indicator showing its status.
Q4: Is the module capable of redundancy?
A4: Yes, it supports redundancy for high reliability applications.
Q5: What voltage level is the module designed for?
A5: The input voltage level supported is 24 VDC.
Q6: How is the module mounted?
A6: It is a plug-in type module for installation on the Ovation backplane.
Q7: What is the operating temperature range for this module?
A7: The working range is 0°C to 60°C, and storage is -40°C to 85°C.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 150 x 120 x 90 mm and the weight is 0.145 kg.
