Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 1C31110G03 |
| Module Type | Digital Input Module |
| Number of Channels | 32 isolated input channels |
| Input Voltage Range | 24 VDC nominal (±10%) |
| Input Type | Current-sinking (NPN-type input) |
| Input Impedance | Approx. 4.3 kΩ |
| Isolation | Optical isolation per channel |
| Input Signal Delay | 10 ms nominal |
| Power Consumption | < 3 W |
| Diagnostic Features | Channel status indicators (LEDs) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (W×H×D) | 150 x 120 x 90 mm |
| Weight | 0.06 kg |
FAQ
FAQ
Q1: How many input channels does the 1C31110G03 module have?
A1: It has 32 digital input channels, suitable for high-density signal acquisition.
Q2: What type of signals does it support?
A2: The module supports dry contact or standard 24 V DC voltage input, widely used in industrial applications.
Q3: Does each input channel have an LED indicator?
A3: Yes, each channel features a status LED for easy monitoring and diagnostics.
Q4: Is there electrical isolation between channels?
A4: Yes, it provides 1500 V RMS isolation between channels and from channels to the system.
Q5: What is the input voltage range supported by the module?
A5: It accepts 0–30 V DC signals, with logic high above 15 V and logic low below 5 V.
Q6: What is the typical scan time per channel?
A6: The scan time is typically less than 1 millisecond per channel.
Q7: How is the module installed?
A7: It uses plug-in installation on an OVATION DCS system backplane, allowing for easy setup.
Q8: Can it operate in humid environments?
A8: Yes, it supports 5% to 95% non-condensing humidity, making it suitable for most industrial settings.
