Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 1C31113G02 |
| Module Type | Analog Input Module |
| Number of Channels | 16 differential or 32 single-ended |
| Input Type | Voltage (±5 V, ±10 V) / Current (4–20 mA) |
| Resolution | 12-bit |
| Input Impedance | >1 MΩ for voltage, 250 Ω for current |
| Isolation | Channel-to-bus and channel-to-channel |
| Accuracy | ±0.1% of full scale |
| Conversion Rate | 20 ms/channel |
| Power Supply | 5 V DC (supplied via backplane) |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 45 x 120 x 200 mm |
| Weight | 0.28 kg |
FAQ
FAQ
Q1: How many analog input channels does the 1C31113G02 module support?
A1: It supports 16 differential or 32 single-ended input channels.
Q2: What type of signal inputs are supported?
A2: It supports voltage inputs (±5 V, ±10 V) and current inputs (4–20 mA).
Q3: What is the input accuracy of the module?
A3: The input accuracy is ±0.1% of full scale.
Q4: Does the module have isolation protection?
A4: Yes, it offers channel-to-bus and channel-to-channel isolation.
Q5: What is the resolution of the input conversion?
A5: The module provides a 12-bit resolution.
Q6: What is the operating temperature range of the module?
A6: The module operates in a range from 0 to 60°C.
Q7: What is the channel conversion rate?
A7: The conversion rate is 20 milliseconds per channel.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 45 x 120 x 200 mm, and the weight is 0.28 kg
