Technical Specifications
| Parameter | Description |
|---|---|
| Model | 1C31116G03 |
| Product Type | Analog Input Module |
| Channels | 8 differential or 16 single-ended |
| Input Signal Range | 0–5 V DC, 1–5 V DC, 0–10 V DC, ±10 V DC |
| Input Type | Voltage |
| Input Impedance | > 1 MΩ |
| Resolution | 12 bits |
| Accuracy | ±0.1% of full scale |
| Scan Rate | 1 ms/channel |
| Isolation | Channel-to-bus: 1500 VDC |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Power Supply | 5 V DC |
| Dimensions | 180 × 35 × 120 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: How many analog input channels does the 1C31116G03 module support?
A1: It supports 8 differential or 16 single-ended analog input channels.
Q2: What input signal ranges are accepted by this module?
A2: It accepts 0–5 V DC, 1–5 V DC, 0–10 V DC, and ±10 V DC signals.
Q3: What is the resolution of the 1C31116G03?
A3: The module provides 12-bit resolution.
Q4: Does this module have electrical isolation?
A4: Yes, it provides 1500 VDC isolation from channels to bus.
Q5: What is the accuracy specification for the module?
A5: The accuracy is ±0.1% of full scale.
Q6: What is the operating temperature range of the module?
A6: The module operates within 0°C to 60°C.
Q7: What is the required power supply for this module?
A7: It operates on 5 V DC power.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 180 × 35 × 120 mm, and the weight is 0.6 kg.
