Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Analog Input Module |
| Model Number | 1C31116G02 |
| Input Type | Single-ended or Differential Analog Input |
| Number of Channels | 8 channels |
| Resolution | 12-bit |
| Input Range | ±5 V, ±10 V (configurable) |
| Analog Input Impedance | ≥10 MΩ |
| Common Mode Rejection | ≥100 dB @ 50/60 Hz |
| Power Supply Voltage | 5 VDC (from backplane) |
| Power Consumption | Approx. 1.0 W |
| Isolation Voltage | Channel to system ground: 250 VAC |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (W×H×D) | 260 × 32 × 176 mm |
| Weight | 0.308 kg |
FAQ
FAQ
Q1: What input signal types does the 1C31116G02 module support?
A1: The module supports both single-ended and differential analog input signals, configurable per channel.
Q2: What is the resolution of this module?
A2: It provides 12-bit resolution suitable for most industrial process measurements.
Q3: What voltage ranges are supported for input signals?
A3: The module supports ±5V and ±10V ranges, which are user-configurable.
Q4: Does the module have input-to-system isolation?
A4: Yes, each channel is isolated from the system ground up to 250 VAC for safety.
Q5: What is the operating temperature range of the module?
A5: It operates in the range of 0°C to 60°C, ideal for industrial environments.
Q6: What is the input impedance of the analog channels?
A6: Each channel has an input impedance of greater than 10 MΩ for precise signal acquisition.
Q7: Is the module hot-swappable?
A7: No, the module does not support hot swapping. Power must be off during replacement.
Q8: What is the function of the 1C31116G02 in the Ovation system?
A8: It serves to acquire analog sensor signals, playing a critical role in accurate process control.
