Technical Specifications
| Parameter | Description |
|---|---|
| Module Model | 1C31116G01 |
| Type | Analog Input Card |
| Number of Channels | 8 differential inputs |
| Input Signal Type | Current signal (4–20 mA) |
| Accuracy | ±0.1% of full scale |
| Resolution | 12-bit |
| Isolation Voltage | Channel-to-system: 1500 V RMS |
| Common Mode Rejection | ≥ 100 dB |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Power Requirements | 5 VDC, max 1.2 W |
| Mounting Type | Slot-mounted in Ovation chassis |
| Dimensions | 45 x 120 x 200 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What type of input signals does the 1C31116G01 support?
A1: The module supports standard 4–20 mA current signals used in most industrial sensors.
Q2: How many input channels are available on the module?
A2: The 1C31116G01 provides 8 differential analog input channels.
Q3: Is there electrical isolation between input channels and the system?
A3: Yes, the module provides 1500 V RMS isolation between channels and the system.
Q4: What is the resolution of this module?
A4: The resolution is 12-bit, suitable for high-precision acquisition.
Q5: What is the operating temperature range?
A5: The module operates in environments ranging from 0°C to 60°C.
Q6: How is the module installed?
A6: The module is slot-mounted into a standard Ovation control chassis.
Q7: Does the module support redundancy?
A7: The module itself does not offer redundancy but can be configured in redundant setups within the Ovation system.
Q8: Does the module have protection or certification?
A8: The module is designed for use inside industrial control cabinets and complies with Ovation system design standards; certifications depend on the overall system compliance.
