Technical Specifications
| Item | Specification |
|---|---|
| Product Model | Ovation 1C31116G05 |
| Product Type | Analog Input Module |
| Input Channels | 16 isolated analog input channels |
| Input Signal Type | Configurable for 4–20 mA current or 0–10 VDC voltage |
| Resolution | 12-bit or higher |
| Accuracy | ±0.1% of full scale |
| Input Impedance | 250 Ω (current), 100 kΩ (voltage) |
| Isolation Voltage | 1500 VDC channel-to-bus |
| Common Mode Rejection Ratio (CMRR) | > 100 dB @ 50/60 Hz |
| Response Time | < 2 ms |
| Power Supply | 24 VDC |
| Power Consumption | 6 W typical |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN rail or rack mount |
| Indicators | Channel and power status LEDs |
| System Compatibility | Ovation Distributed Control System (DCS) |
| Dimensions | 180 × 35 × 120 mm |
| Weight | 0.113 kg |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31116G05 module?
A1: It collects analog signals such as current or voltage from field devices and transmits them to the Ovation control system.
Q2: What types of input signals does the module support?
A2: It supports configurable 4–20 mA current and 0–10 VDC voltage input signals.
Q3: How many input channels does the module provide?
A3: The module offers 16 isolated analog input channels.
Q4: What is the accuracy of the module?
A4: The measurement accuracy is ±0.1% of full scale.
Q5: What is the module’s response time?
A5: The response time is less than 2 milliseconds, suitable for fast and accurate measurements.
Q6: Does the module have isolation protection?
A6: Yes, it provides 1500 VDC isolation between channels and the system bus.
Q7: What are the module’s dimensions and weight?
A7: Dimensions are 180 × 35 × 120 mm and weight is 0.113 kg.
Q8: Which systems is the module compatible with?
A8: It is compatible with the Ovation Distributed Control System (DCS).
