Technical Specifications
| Item | Specification |
|---|---|
| Product Model | Ovation 1C31179G02 |
| Product Type | Remote Input/Output Module |
| Communication Interface | RS-485 or Ethernet (depending on configuration) |
| Communication Protocol | Ovation proprietary I/O communication protocol |
| I/O Support | Supports multiple analog and digital I/O module connections |
| Data Update Rate | Up to 10 ms |
| Power Supply | 24 VDC |
| Power Consumption | 8 W typical |
| Isolation Voltage | 1500 VDC between communication and power circuits |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN rail or rack mount |
| Indicators | Communication and power status LEDs |
| System Compatibility | Ovation Distributed Control System (DCS) |
| Dimensions | 250 × 40 × 180 mm |
| Weight | 1.3 kg |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31179G02 module?
A1: It is used to handle remote input and output signal acquisition and transmission within the Ovation DCS system.
Q2: How does the module communicate with the main control system?
A2: It communicates via RS-485 or Ethernet interfaces with Ovation controllers.
Q3: What types of I/O signals does the module support?
A3: It supports connections with digital input, digital output, analog input, and analog output modules.
Q4: What is the module’s data update rate?
A4: The data update rate can reach up to 10 ms.
Q5: What indicator functions does the module include?
A5: It includes communication and power status LEDs.
Q6: What are the power requirements of the module?
A6: It requires a 24 VDC power supply.
Q7: What are the dimensions and weight of the module?
A7: Dimensions are 250 × 40 × 180 mm and weight is 1.3 kg.
Q8: Which systems is the module compatible with?
A8: It is compatible with the Ovation Distributed Control System (DCS).
