Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 1C31232G03 |
| Series | Ovation |
| Type | Digital Input Module |
| Number of Channels | 16 digital input channels |
| Input Signal Type | Discrete DC voltage inputs |
| Input Voltage Range | 0–30 VDC |
| Logic “1” Threshold | ≥15 VDC |
| Logic “0” Threshold | ≤5 VDC |
| Input Current | <5 mA per channel |
| Input Isolation | 2500 V RMS channel-to-system isolation |
| Response Time | <5 ms |
| Power Supply | 24 VDC nominal |
| Diagnostics | Channel status LEDs and onboard self-diagnostics |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Mounting Type | Rack Mount |
| Environmental Rating | IP20 |
| Compatibility | Ovation Control and I/O System |
| Dimensions | 159 x 120 x 35 mm |
| Shipping Weight | 0.39 kg |
FAQ
FAQ
Q1: What is the function of the Ovation 1C31232G03 Digital Input Module?
A1: It is used to acquire discrete on/off signals from field equipment and transmit them to the Ovation control system for monitoring and control functions.
Q2: How many input channels does the module provide?
A2: The module provides 16 isolated digital input channels.
Q3: What is the acceptable voltage range for the inputs?
A3: The inputs accept DC signals ranging from 0 to 30 VDC.
Q4: What are the logic level thresholds for input detection?
A4: Logic “1” is recognized at voltages ≥15 VDC, and logic “0” is recognized at voltages ≤5 VDC.
Q5: Does the module feature electrical isolation?
A5: Yes, it provides 2500 V RMS isolation between input channels and the system, ensuring protection and signal integrity.
Q6: What diagnostic functions are built into the module?
A6: The module includes LED indicators for each channel and self-diagnostic routines for detecting faults or abnormal signal conditions.
Q7: What is the module’s input response time?
A7: The typical response time is less than 5 milliseconds, ensuring rapid signal acquisition and accurate system control.
Q8: How is the 1C31232G03 module integrated into the Ovation system?
A8: It is installed in a rack-based configuration within the Ovation I/O subsystem, allowing efficient communication with the control processor via the system backplane.
