Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 1C31233G01 |
| Series | Ovation |
| Type | Digital Input Module |
| Number of Channels | 16 digital input channels |
| Input Signal Type | Discrete DC voltage inputs |
| Input Voltage Range | 0–30 VDC |
| Logic “1” Threshold | ≥15 VDC |
| Logic “0” Threshold | ≤5 VDC |
| Input Current | <5 mA per channel |
| Input Isolation | 2500 V RMS channel-to-system isolation |
| Response Time | <5 ms |
| Power Supply | 24 VDC nominal |
| Input Protection | Overvoltage and reverse polarity protection |
| Diagnostics | Channel status LEDs and onboard self-diagnostics |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Mounting Type | Rack Mount |
| Environmental Rating | IP20 |
| Compatibility | Ovation Control and I/O System |
| Dimensions | 50 × 240 × 200 mm |
| Shipping Weight | 1.4 kg |
FAQ
FAQ
Q1: What is the primary function of the Ovation 1C31233G01 Digital Input Module?
A1: It is designed to receive and process discrete digital signals from field devices, converting them into logic data for use in the Ovation control system.
Q2: How many channels are available on this module?
A2: The module features 16 isolated digital input channels for flexible field signal interfacing.
Q3: What is the acceptable voltage range for the input channels?
A3: Each input channel accepts DC voltage signals in the range of 0–30 VDC.
Q4: What are the logic level thresholds of this module?
A4: Logic “1” is detected at voltages greater than or equal to 15 VDC, and logic “0” is detected at voltages less than or equal to 5 VDC.
Q5: Does the 1C31233G01 provide isolation between input and system circuits?
A5: Yes, it provides 2500 V RMS isolation, ensuring protection against electrical noise and transient interference.
Q6: What diagnostic features are included with this module?
A6: The module includes per-channel LED indicators and built-in self-diagnostic capabilities for fault and signal integrity monitoring.
Q7: How quickly does the module respond to signal changes?
A7: It provides a fast response time of less than 5 milliseconds for real-time signal processing.
Q8: How is the module typically installed within the Ovation system?
A8: It is mounted in a rack assembly within the Ovation I/O subsystem, ensuring secure electrical connections and easy accessibility for maintenance.
