Technical Specifications
| Item | Specification |
|---|---|
| Model | Ovation 1X00024H03 |
| Product Type | Power Supply Module |
| Function | System power distribution and regulation |
| Input Voltage Range | 110–240 V AC |
| Input Frequency | 50 / 60 Hz |
| Output Voltage | 24 V DC |
| Rated Output Current | 20 A |
| Output Power | 480 W |
| Regulation Type | Switching power supply |
| Efficiency | ≥ 88% |
| Output Ripple and Noise | < 120 mV |
| Protection Functions | Overvoltage, overcurrent, short-circuit, overtemperature |
| Isolation Strength | Input/output reinforced isolation |
| Cooling Method | Forced air cooling |
| Power Redundancy | Supports parallel operation |
| Hold-up Time | > 20 ms at full load |
| Inrush Current Limiting | Integrated |
| Status Indication | Power OK LED |
| Alarm Output | Dry contact fault relay |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -25°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Mounting Method | Rack or panel mount |
| Dimensions (L × W × H) | 250 × 200 × 120 mm |
| Weight | 2.5 kg |
FAQ
FAQ
Q1: What is the primary role of the 1X00024H03 module?
A1: It provides stable DC power for Ovation control systems and connected field components.
Q2: Does this power supply support a wide input voltage range?
A2: Yes, it accepts global AC voltage from 110 V to 240 V.
Q3: Can multiple units be connected for redundancy?
A3: Yes, parallel operation is supported to achieve system redundancy.
Q4: How is output stability maintained during load changes?
A4: High-speed regulation circuitry compensates for dynamic load variations.
Q5: What protection mechanisms are built into the module?
A5: It includes protection against overcurrent, overvoltage, short-circuit, and overheating.
Q6: Is there a system-level alarm signal available?
A6: Yes, a relay output provides power-failure and fault status feedback.
Q7: How is cooling managed inside the unit?
A7: Internal fans provide active cooling for high-load operation.
Q8: What happens during an input power interruption?
A8: Internal energy storage maintains output long enough for controlled system handling.
