Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Analog Input Module |
| Model Number | 5X00106G01 |
| Brand | Ovation |
| Product Type | Analog Input I/O Module |
| Function | Converts analog signals from field devices into digital data for Ovation control system processing |
| Number of Channels | 8 differential analog input channels |
| Input Signal Range | 4–20 mA or 0–10 V DC (software selectable) |
| Input Impedance | > 250 Ω (current), > 100 kΩ (voltage) |
| Accuracy | ±0.1% of full scale |
| Resolution | 12-bit or higher A/D conversion |
| Isolation | 500 V channel-to-bus and channel-to-channel isolation |
| Sampling Rate | 10 samples per second per channel |
| Common Mode Rejection Ratio (CMRR) | > 100 dB |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | < 5 W typical |
| Signal Filtering | Programmable digital filtering for noise suppression |
| Diagnostics | Continuous self-test and fault monitoring |
| Communication Interface | Ovation I/O system bus |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Installation | Plug-in type for standard Ovation I/O rack |
| Dimensions | 263 x 183 x 55 mm |
| Weight | 0.29 kg |
FAQ
FAQ
Q1: What is the primary function of the Ovation 5X00106G01 Analog Input Module?
A1: It acquires analog signals from sensors or transmitters and converts them into digital values for the Ovation control system.
Q2: What types of signals can this module process?
A2: The module can process both 4–20 mA current signals and 0–10 V DC voltage signals, configurable per channel.
Q3: How many analog input channels are available on this module?
A3: It provides 8 differential analog input channels.
Q4: Is channel-to-channel isolation provided?
A4: Yes, each channel is isolated to prevent interference and ensure signal integrity.
Q5: Does the module support diagnostics?
A5: Yes, it includes continuous self-test, open-circuit detection, and fault monitoring.
Q6: How does this module communicate with the Ovation system?
A6: It connects directly to the Ovation I/O system bus for seamless integration with the control system.
Q7: Can each input channel be individually configured?
A7: Yes, each of the 8 channels can be independently set for current or voltage input.
Q8: Where is the 5X00106G01 Analog Input Module typically used?
A8: It is commonly used in power plants, chemical plants, and industrial automation environments requiring precise analog data acquisition.
