Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Ovation 5X00121G01 |
| Type | 8 Channel RTD Input Module |
| Function | Measures resistance temperature detectors (RTDs) and converts signals to digital format |
| Number of Channels | 8 channels |
| RTD Types Supported | Pt100, Pt1000 |
| Measurement Range | -200°C to +850°C (depending on RTD type) |
| Input Accuracy | ±0.1% of reading |
| Resolution | 16-bit |
| Excitation Current | 0.5 mA per channel |
| Sampling Rate | 250 ms per channel (typical) |
| Signal Filtering | Software and hardware filtering available |
| Communication Interface | Ovation Network |
| Power Supply Voltage | 24 VDC nominal |
| Power Consumption | <10 W |
| Diagnostic Features | Open RTD detection, sensor fault alarms |
| Status Indication | Channel and module status LEDs |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5%–95% non-condensing |
| Mounting Type | DIN-rail or card rack installation |
| Dimensions (HxWxD) | 100 × 160 × 220 mm |
| Weight | 0.32 kg |
FAQ
FAQ
Q1: What types of RTDs are supported by this module?
A1: The module supports Pt100 and Pt1000 resistance temperature detectors.
Q2: How many channels does the 5X00121G01 provide?
A2: It provides 8 individual RTD input channels.
Q3: What is the measurement range for the inputs?
A3: Depending on the RTD type, the module measures from -200°C to +850°C.
Q4: Does the module provide diagnostics for faulty sensors?
A4: Yes, it detects open RTDs and provides sensor fault alarms.
Q5: What is the typical input accuracy of this module?
A5: The module offers ±0.1% of reading accuracy.
Q6: How fast does the module sample the RTD signals?
A6: The typical sampling rate is 250 ms per channel.
Q7: What interfaces are used to communicate with the Ovation system?
A7: The module communicates via the Ovation Network interface.
Q8: Are there any filtering options for the RTD signals?
A8: Yes, both software and hardware signal filtering are available for improved measurement stability.
