Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | Schneider 140AII33010 |
| Module Type | Intrinsically Safe Current Input Module |
| Number of Channels | 8 Intrinsically Safe Analog Input Channels |
| Input Type | 4–20 mA Current Signal |
| Safety Rating | Intrinsically Safe (ATEX and IECEx certified) |
| Resolution | 15-bit |
| Isolation Type | Channel-to-channel and channel-to-system |
| Input Impedance | Typically 250 ohms |
| Accuracy | ±0.1% of full scale |
| Sampling Rate | Approx. 10 samples/sec per channel |
| Power Supply | 5V DC (supplied by the backplane) |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting | Rack-mounted (Modicon Quantum Series) |
| Dimensions | 47 x 162 x 315 mm |
| Weight | 0.795 kg |
FAQ
FAQ
Q1: What types of sensors are supported by this module?
A1: It supports intrinsically safe 4–20 mA current input sensors.
Q2: Does each channel have individual isolation protection?
A2: Yes, each channel is isolated from the others and from the system.
Q3: Is the 140AII33010 module ATEX certified?
A3: Yes, it is certified under ATEX and IECEx for intrinsic safety.
Q4: How many channels can this module handle?
A4: The module supports up to 8 analog input channels.
Q5: How is the module installed?
A5: It is rack-mounted in the Modicon Quantum series system.
Q6: Is external power required for the module?
A6: No, it is powered by the backplane with a 5V DC supply.
Q7: What is the operating temperature range?
A7: 0°C to 60°C for operation, -40°C to 85°C for storage.
Q8: What is the input impedance of the module?
A8: The typical input impedance is 250 ohms.
