Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 140CPU21304 |
| Product Type | CPU Controller |
| Manufacturer | Schneider Electric |
| Series | Concept PLC |
| Processor Type | 32-bit Microprocessor |
| Operating System | Concept Operating System |
| Program Memory | 256 KB RAM, 512 KB Flash |
| Data Memory | 128 KB RAM |
| Communication Ports | Ethernet, RS-232, RS-485 |
| Scan Time | Typical 1 ms per 1,000 instructions |
| I/O Compatibility | Compatible with Concept Series I/O Modules |
| Input Voltage | 24 V DC |
| Output Voltage | 24 V DC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Cooling Method | Natural Convection |
| Mounting Type | DIN Rail or Panel Mount |
| Status Indicators | LED indicators for Power, Run, Fault |
| Programming Software | Concept Developer Suite |
| Certifications | CE, UL, CSA, IEC Standards |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.798 kg |
FAQ
FAQ
Q1: What is the primary function of the Schneider 140CPU21304 CPU Controller?
A1: The 140CPU21304 acts as the central processing unit in Concept PLC systems, executing control programs, managing I/O operations, and coordinating communication with other devices and modules.
Q2: Which communication interfaces are supported by this controller?
A2: It supports Ethernet for network integration and RS-232/RS-485 for serial communication, allowing flexible connectivity with a wide range of industrial devices.
Q3: What are the memory specifications for program and data storage?
A3: The CPU includes 256 KB RAM and 512 KB Flash for program storage, and 128 KB RAM for data, enabling it to handle complex automation processes efficiently.
Q4: How can the operational status of the CPU Controller be monitored?
A4: Front-mounted LED indicators provide real-time feedback on Power, Run, and Fault conditions, allowing operators to quickly assess system status.
Q5: Is the 140CPU21304 compatible with Concept Series I/O modules?
A5: Yes, it is fully compatible with Concept I/O modules, supporting flexible system expansion and seamless integration within the Concept PLC ecosystem.
Q6: Which software is used for programming this CPU Controller?
A6: The processor is programmed using the Concept Developer Suite, which offers tools for logic design, configuration, and system monitoring.
Q7: Can this CPU Controller operate in typical industrial environments?
A7: Yes, it is designed to operate reliably in temperatures ranging from 0°C to +55°C, suitable for standard industrial conditions.
Q8: How does the CPU Controller ensure reliable control execution?
A8: The combination of its 32-bit processor, deterministic scan cycles, and robust memory management ensures precise execution of control programs and stable interaction with connected I/O devices.
