Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 140CPU21304C |
| Product Type | CPU Controller |
| Manufacturer | Schneider Electric |
| Series | Concept PLC |
| Processor Type | 32-bit Microprocessor |
| Operating System | Concept Operating System |
| Program Memory | 256 KB RAM, 512 KB Flash |
| Data Memory | 128 KB RAM |
| Communication Ports | Ethernet, RS-232, RS-485 |
| Scan Time | Typical 1 ms per 1,000 instructions |
| I/O Compatibility | Compatible with Concept Series I/O Modules |
| Input Voltage | 24 V DC |
| Output Voltage | 24 V DC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Cooling Method | Natural Convection |
| Mounting Type | DIN Rail or Panel Mount |
| Status Indicators | LED indicators for Power, Run, Fault |
| Programming Software | Concept Developer Suite |
| Certifications | CE, UL, CSA, IEC Standards |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.798 kg |
FAQ
FAQ
Q1: What distinguishes the Schneider 140CPU21304C from other Concept CPUs?
A1: The 140CPU21304C provides enhanced processing capabilities and communication reliability, designed for medium-scale industrial automation tasks with improved firmware stability and faster instruction execution.
Q2: What communication options are available for this controller?
A2: It includes Ethernet, RS-232, and RS-485 interfaces, enabling flexible communication with HMIs, SCADA systems, and other networked automation equipment.
Q3: What kind of memory resources does this CPU have for application programming?
A3: The module is equipped with 256 KB of RAM for program execution, 512 KB of Flash memory for storage, and an additional 128 KB of RAM for data handling, supporting large control programs.
Q4: How can users monitor the operational state of the 140CPU21304C?
A4: The front panel provides LED status indicators showing Power, Run, and Fault conditions, offering quick visual feedback for maintenance and troubleshooting.
Q5: Is the CPU compatible with existing Concept I/O modules?
A5: Yes, it is fully compatible with all Concept Series I/O modules, allowing seamless integration into existing systems without additional configuration adjustments.
Q6: Which software tool is used to program the 140CPU21304C?
A6: Programming and configuration are performed using the Concept Developer Suite, which provides a user-friendly interface for logic development, diagnostics, and communication setup.
Q7: What kind of environmental conditions can the controller operate in?
A7: The CPU is built to function reliably within a temperature range of 0°C to +55°C and can withstand industrial conditions such as vibration and electrical noise.
Q8: How does the controller ensure reliable operation in process automation systems?
A8: It combines a high-performance 32-bit processor, deterministic control cycles, and robust memory management to ensure precise execution and system stability in demanding control environments.
