Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Product Model | 140CPU65260 |
| Product Type | Unity Processor Module |
| Processor Type | Motorola MPC860 PowerPC RISC Processor |
| Processor Speed | 66 MHz |
| Program Memory Capacity | 2048 kB |
| Data Memory | 512 kB SRAM, battery-backed |
| Flash Memory | 8 MB |
| Instruction Execution Speed | 0.15 µs/Boolean Instruction |
| Programming Environment | Unity Pro / EcoStruxure Control Expert |
| Communication Ports | Ethernet (10/100 Mbps), Modbus Plus, Modbus, RS-232, RS-485 |
| Integrated Protocols | Modbus TCP/IP, Modbus RTU, Modbus Plus, Ethernet Global Data (EGD) |
| Backplane Compatibility | Quantum Series Backplane |
| Diagnostic Functions | Built-in LED indicators for status, communication, and error monitoring |
| Redundancy Support | Yes, supports Hot Standby (HSBY) redundancy |
| Power Requirements | 5 V DC, 850 mA |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted (Quantum rack) |
| Dimensions | Package dimensions: 110 x 185 x 330 mm |
| Weight | Package weight 1.432 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the Schneider 140CPU65260 used for?
It is a high-performance Unity Processor for Modicon Quantum PLCs, designed for complex automation, process control, and redundancy applications.
Q2: Which programming software is compatible with this processor?
It can be programmed using Unity Pro or EcoStruxure Control Expert software.
Q3: Does it support Hot Standby redundancy?
Yes, the 140CPU65260 supports Hot Standby (HSBY) mode for seamless redundancy.
Q4: What communication protocols does it support?
It supports Modbus TCP/IP, Modbus RTU, Modbus Plus, and Ethernet Global Data (EGD).
Q5: How much memory does the processor have?
It includes 2048 kB program memory, 512 kB SRAM (battery-backed), and 8 MB Flash memory.
Q6: Is it compatible with Quantum series racks and I/O modules?
Yes, it is fully compatible with Modicon Quantum series racks and standard I/O modules.
Q7: What is the typical power requirement for this processor?
It requires 5 V DC power at 850 mA.
Q8: How can users monitor system operation and errors?
It includes built-in LED indicators that show RUN, ERROR, COMM, and STATUS for easy system diagnostics.
