Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Product Model | 140CRP31200 |
| Product Type | Quantum Ethernet Remote I/O (RIO) Head Module |
| Processor Type | Integrated communication processor |
| Communication Interface | Ethernet (10/100 Mbps) |
| Supported Network | Modbus TCP/IP |
| Connection Type | RJ45 Ethernet port |
| Maximum Number of Drops | Up to 31 RIO drops |
| Data Transfer Rate | 10/100 Mbps, auto-negotiation |
| Bus Type | Quantum Remote I/O bus |
| I/O Update Time | Less than 15 ms (typical) |
| Status Indicators | LED indicators for power, communication, and network status |
| Configuration Software | Unity Pro / EcoStruxure Control Expert |
| Power Requirements | 5 V DC, 800 mA |
| Mounting Type | Rack-mounted (Quantum series backplane) |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 50 x 167 mm |
| Weight | 0.554 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the Schneider 140CRP31200?
It acts as the Ethernet RIO head module that connects a Quantum controller to remote I/O stations over an Ethernet network.
Q2: Which communication protocol does this module support?
It supports Modbus TCP/IP for reliable and fast data transmission between the controller and remote I/O.
Q3: How many remote drops can the module manage?
The module can handle up to 31 RIO drops within a single network.
Q4: What software is used to configure this module?
It is configured using Unity Pro or EcoStruxure Control Expert software.
Q5: Can this module be used with other Quantum series components?
Yes, it is fully compatible with Quantum backplanes, power supplies, and I/O modules.
Q6: How does the module indicate its operational status?
LED indicators provide visual feedback for power, communication, and network link activity.
Q7: What is the typical I/O update time?
The typical I/O update time is less than 15 milliseconds, ensuring responsive control performance.
Q8: What are the installation and environmental requirements?
It is designed for rack mounting in Quantum systems, with an operating temperature range of 0–60°C and 5–95% non-condensing humidity.
