Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric 140NOE77101C |
| Manufacturer | Schneider Electric |
| Product Series | Modicon Quantum |
| Product Type | Ethernet Network TCP/IP Communication Module |
| Function | Provides Ethernet communication capability for Modicon Quantum PLC systems |
| Application | Industrial Ethernet networking, PLC communication, SCADA integration, remote I/O communication |
| Communication Protocol | Ethernet Modbus TCP/IP |
| Concept | Transparent Ready |
| Web Server | Class B30 |
| Web Services | Data Editor, Rack Viewer, Diagnostics via Web Pages |
| Communication Services | Modbus TCP Messaging, I/O Scanning, Global Data, FDR Server, SNMP Network Management, Bandwidth Management |
| Ethernet Ports | 1 × RJ45 10/100BASE-TX + 1 × MT/RJ 100BASE-FX Fiber Optic |
| Transmission Rate | 10/100 Mbps |
| Redundancy | Supports Hot Standby Redundant Architecture |
| Power Supply | Supplied through Quantum rack power supply |
| Power Consumption | 750 mA at 5 VDC |
| Module Format | Standard Quantum Module |
| Installation Location | Quantum PLC Backplane |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Certifications | UL 508, CSA C22.2 No.142, FM Class 1 Division 2 |
| LED Indicators | Ethernet status, link, activity, fault, ready, communication status |
| Conformal Coating | Included |
| Dimensions | Approx. 27.5 × 135 × 141.5 mm (W × H × D) |
| Weight | Approx. 0.34 kg |
FAQ
FAQ
Q1: What is the Schneider Electric 140NOE77101C used for?
A: The 140NOE77101C is used to add Ethernet communication capability to Modicon Quantum PLC systems, enabling PLC networking, SCADA communication, and industrial Ethernet data exchange.
Q2: Which PLC platform is compatible with the 140NOE77101C?
A: This module is designed for the Schneider Electric Modicon Quantum automation platform and installs directly into the Quantum rack backplane.
Q3: What communication protocols does this module support?
A: The module supports Ethernet Modbus TCP/IP, including Modbus TCP messaging, I/O scanning, Global Data, SNMP network management, and FDR services.
Q4: What Ethernet interfaces are available on the 140NOE77101C?
A: The module provides one RJ45 10BASE-T/100BASE-TX copper Ethernet port and one MT/RJ 100BASE-FX multimode fiber optic port.
Q5: Does the 140NOE77101C support redundant systems?
A: Yes. The module supports hot standby redundant architecture for applications requiring increased system availability.
Q6: What are the dimensions and weight of the 140NOE77101C?
A: The module dimensions are approximately 27.5 × 135 × 141.5 mm, with a weight of approximately 0.34 kg.
Q7: Is the Schneider Electric 140NOE77101C still available?
A: The 140NOE77101C has been discontinued. Schneider Electric lists replacement options from the Modicon M580 series, such as the BMENOC0301C Ethernet communication module, depending on system requirements.
Q8: What should be checked before installing the 140NOE77101C?
A: Before installation, verify Quantum PLC rack compatibility, available power supply capacity, Ethernet network configuration, IP addressing, communication settings, and environmental conditions to ensure reliable operation.
