Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Ethernet TCP/IP Communication Module |
| Network Protocols | Modbus TCP/IP, Ethernet TCP/IP |
| Supported Topologies | Star, line, and switched Ethernet networks |
| Connector Type | RJ45 (10/100 Mbps auto-negotiation) |
| IP Configuration | Static or DHCP assignment |
| Routing Capability | Integrated routing between Ethernet and PLC backplane |
| Data Exchange | Supports global data, messaging, and I/O scanning |
| Diagnostics | Link status, network errors, module health |
| Security Features | Configurable access control and port parameters |
| Supported PLC Platform | Modicon Quantum series |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Power Consumption | From backplane; optimized for low-load operation |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What communication speeds does the 140NOE77110C support?
A1: It supports 10 Mbps and 100 Mbps with automatic speed and duplex detection.
Q2: Does the module support Modbus TCP/IP I/O scanning?
A2: Yes, it can scan multiple Modbus TCP devices for real-time I/O data exchange.
Q3: How is the Ethernet IP address configured?
A3: It can be set manually through configuration software or assigned automatically using DHCP.
Q4: Can the module perform routing between different network segments?
A4: Yes, it includes built-in routing functions that allow communication across Ethernet and the Quantum backplane.
Q5: What type of diagnostic information does the module provide?
A5: It offers link status, packet error counts, port activity, and module health information.
Q6: Is redundancy supported on Ethernet networks?
A6: The module can participate in redundant network topologies using external switches that support redundancy protocols.
Q7: Does the module support peer-to-peer communication between Quantum PLCs?
A7: Yes, peer messaging is supported for controller-to-controller data exchange.
Q8: How does the module handle network load during high traffic?
A8: It features internal buffering and optimized packet management to maintain stable communication under heavy network activity.
