Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | DIO Head-end Adaptor |
| Purpose | Interface module for distributed I/O communication in Modicon Quantum systems |
| Supported Network | Remote I/O network for DIO architecture |
| Communication Method | High-speed serial link between head-end and remote I/O drops |
| Backplane Compatibility | Modicon Quantum rack |
| Data Handling | Supports deterministic exchange of discrete signals |
| Status Indication | Module status LEDs for communication and module health |
| Configuration Method | Set via Unity/Control Expert software |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Power Source | Draws power from the Quantum backplane |
| Diagnostics | Online monitoring of channel status, communication integrity, and fault detection |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.49 kg |
FAQ
FAQ
Q1: What is the primary function of the 140NOM21100C module?
A1: It serves as the head-end adaptor for DIO networks, enabling communication between the Quantum PLC and distributed remote I/O stations.
Q2: Does the module support deterministic I/O communication?
A2: Yes, the DIO architecture ensures predictable, time-controlled exchange of discrete signals.
Q3: How is the module configured within the control system?
A3: Configuration is performed through Unity Pro / EcoStruxure Control Expert.
Q4: What diagnostic information does the module provide?
A4: It offers real-time status LEDs and software-accessible diagnostics for communication state, channel faults, and module health.
Q5: Is the module compatible with all Quantum racks?
A5: Yes, it is designed to operate on standard Quantum backplanes.
Q6: Can the module support multiple remote I/O drops?
A6: Yes, it supports multiple remote stations depending on network architecture and system design.
Q7: Does the module require any external power supply?
A7: No, it draws all necessary power directly from the Quantum rack backplane.
Q8: How does the head-end adaptor handle communication faults?
A8: It uses built-in error detection and reporting, allowing the PLC to diagnose and react to communication disruptions.
