Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider 140SAI94000S |
| Product Type | Analog Safety Input Module |
| Series | Modicon Safety / 140 Series |
| Function | Monitors analog signals from field devices in safety applications and communicates data to safety PLCs |
| Input Channels | 4 analog input channels |
| Input Signal Range | 0–20 mA, 4–20 mA, 0–10 V (configurable) |
| Accuracy | ±0.2% of full scale |
| Resolution | 12-bit ADC |
| Response Time | <10 ms per channel |
| Isolation | Channel-to-channel and channel-to-backplane isolation |
| Power Supply | 24 V DC nominal |
| Mounting Type | DIN rail or backplane compatible |
| LED Indicators | Status and fault LEDs per channel |
| Dimensions | Package size: 47 x 162 x 315 mm |
| Weight | Package weight 0.5 kg |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Safety Certification | SIL3, IEC 61508, EN 62061 |
| Application | Used in safety PLC systems for monitoring critical analog inputs from sensors such as pressure, temperature, and flow transmitters |
| Communication | Works with Modicon safety PLCs for secure analog signal monitoring |
FAQ
FAQ
Q1: What is the main function of the 140SAI94000S module?
A1: It monitors analog signals in safety systems and provides reliable data to safety PLCs.
Q2: How many input channels does the module have?
A2: It has 4 analog input channels.
Q3: What types of input signals are supported?
A3: Supports 0–20 mA, 4–20 mA, and 0–10 V, configurable per channel.
Q4: What is the resolution and accuracy?
A4: 12-bit ADC with ±0.2% full-scale accuracy.
Q5: Does it provide isolation protection?
A5: Yes, channel-to-channel and channel-to-backplane isolation.
Q6: Does the module have status indicators?
A6: Yes, each channel has status and fault LEDs.
Q7: Which safety certifications does it support?
A7: Supports SIL3, IEC 61508, and EN 62061 certifications.
Q8: What should be noted during installation?
A8: Ensure secure DIN rail or backplane mounting, avoid static discharge, and check LED indicators for proper operation.
