Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric ATV312HD15N4 |
| Product Series | Altivar 312 Variable Frequency Drive (VFD) |
| Product Type | Three-phase AC motor speed controller |
| Rated Motor Power | 15 kW (20 HP) – for asynchronous motors |
| Supply Voltage | 380–500 VAC, three-phase |
| Supply Frequency | 50/60 Hz |
| Rated Line Current | ≈ 48.2 A @ 380 V, ≈ 36.8 A @ 500 V |
| Output Frequency Range | 0 – 500 Hz (variable) |
| Control Method | Sensorless flux vector control with PWM type motor control |
| EMC Filter | Integrated EMC filter |
| Communications | Modbus, CANopen (supported on Altivar 312 series) |
| Protection Rating | IP20 (with higher terminal ratings in some configurations) |
| Standards & Approvals | IEC 61800-3, IEC 61800-5-1, UL, CSA, C-Tick, GOST, NOM |
| Operating Temp | −10 °C to +50 °C (typical) |
| Mounting | Vertical panel mount (±10°) |
| Dimensions (W × H × D) | 245 mm × 329.5 mm × 192 mm (approx.) |
| Net Weight | ≈ 11 kg (≈ 24.25 lb) |
| Typical Use | Variable speed and torque control of three-phase motors in industrial systems and simple machines |
FAQ
FAQ
Q1: What is the main purpose of the ATV312HD15N4?
It is used as a variable frequency drive (VFD) to control the speed and torque of three-phase AC asynchronous motors by adjusting output frequency and voltage for energy-efficient performance.
Q2: What motor power and voltage range does this VFD support?
This model supports motors up to 15 kW (20 HP) and operates on a three-phase 380–500 VAC supply.
Q3: What is the typical output frequency range?
The drive can vary the output frequency from 0 up to about 500 Hz, allowing flexible motor speed control.
Q4: Does the ATV312HD15N4 have an EMC filter?
Yes — it includes an integrated EMC filter to help meet electromagnetic compatibility requirements in industrial environments.
Q5: What are the physical size and weight of this drive?
The VFD measures approximately 245 mm wide × 329.5 mm high × 192 mm deep and has a net weight of about 11 kg.
Q6: What protection rating does this model have?
It carries an IP20 protection rating suitable for indoor industrial environments; additional terminal ratings like IP21 or higher may apply with covers.
Q7: What communications protocols are supported?
The Altivar 312 series, including this model, supports Modbus and CANopen for integration with automation and PLC systems.
Q8: What safety and industry standards does this drive comply with?
It complies with key industrial standards including IEC 61800-3, IEC 61800-5-1, and certifications such as UL, CSA, C-Tick, GOST, and NOM.
