Technical Specifications
| Parameter | Description |
|---|---|
| Product | Schneider Electric ATV320U40N4B |
| Series | Altivar Machine ATV320 |
| Model Number | ATV320U40N4B |
| Drive Type | Variable Frequency Drive (VFD) |
| Rated Motor Power | 4.0 kW (5 HP) heavy duty |
| Supply Voltage | 3-phase, 380–500 V AC ±15 % / +10 % |
| Supply Frequency | 50 / 60 Hz |
| Rated Output Current | 9.5 A |
| Output Frequency Range | 0.1–599 Hz |
| Control Methods | V/F control; Sensorless Vector Control |
| EMC Filter | Integrated Class C2 |
| Communication Interfaces | Modbus serial, CANopen (RJ45 port) |
| Safety Functions | Safe Torque Off (STO), Safe Stop 1 (SS1) |
| Protection Functions | Overcurrent, Overvoltage, Undervoltage, Thermal, Short-circuit |
| Protection Rating | IP20 |
| Cooling Method | Internal fan |
| Mounting | Cabinet / vertical panel mount (+/-10°) |
| Discrete Inputs | 7 programmable |
| Switching Frequency | 2–16 kHz adjustable (4 kHz nominal) |
| Braking to Standstill | DC injection; Brake chopper integrated |
| Operating Temperature | −10 °C to +50 °C (without derating) |
| Storage Temperature | −25 °C to +70 °C |
| Dimensions (H × W × D) | 325 × 60 × 245 mm |
| Weight | 3.0 kg |
FAQ
FAQ
Q1: What motor power is the ATV320U40N4B designed for?
It is designed for 4.0 kW (5 HP) three-phase heavy-duty motor applications.
Q2: What supply voltage and frequency range does this drive require?
This drive operates on a three-phase 380–500 V AC supply at 50 / 60 Hz.
Q3: What is the nominal output current of the ATV320U40N4B?
The nominal output current is 9.5 A.
Q4: What control methods does this model support?
It supports V/F control and sensorless vector control for flexible speed and torque management.
Q5: Does the drive include safety functions?
Yes, it includes safety features like Safe Torque Off (STO) and Safe Stop 1 (SS1).
Q6: What protection rating and functions does the ATV320U40N4B have?
It has an IP20 protection rating and offers overcurrent, overvoltage, undervoltage, thermal, and short-circuit protections.
Q7: What are the physical dimensions and weight of this drive?
The drive measures about 325 × 60 × 245 mm and weighs approximately 3.0 kg.
Q8: What communication interfaces are supported?
It supports Modbus serial and CANopen communication via the integrated RJ45 port.
