Technical Specifications
| Parameter | Description |
|---|---|
| Product | ATV61HD30N4 – Schneider Electric Altivar 61 Variable Frequency Drive |
| Series | Altivar 61 |
| Model Number | ATV61HD30N4 |
| Drive Type | Variable Frequency Drive (VFD) |
| Rated Motor Power | 30 kW (40 HP) three‑phase industrial motor control |
| Supply Voltage | 3‑phase, 380 – 480 V AC (‑15 % / +10 %) |
| Supply Frequency | 50 / 60 Hz |
| Output Current (Nominal) | 56 A @ 480 V; 66 A @ 380 V |
| Output Frequency Range | 0.1 – 599 Hz |
| Control Methods | Voltage/Frequency (V/F) control, sensorless vector control (flux vector) |
| EMC Filter | Integrated Level 3 EMC filter |
| Communication Interfaces | CANopen, Modbus (optional or integrated depending on configuration) |
| Protection Functions | Overcurrent, overvoltage, undervoltage, thermal and short‑circuit protections (industry standard) |
| Protection Rating | IP20 / IEC standard indoor enclosure |
| Switching Frequency | Adjustable ~1 – 16 kHz (nominal ~12 kHz) |
| Braking | DC injection braking with options for braking resistor (application dependent) |
| Mounting | Vertical panel / wall mount with heatsink (heat sink assembly) |
| Operating Temperature | −10 °C to +50 °C (no derating typical) |
| Storage Temperature | −25 °C to +70 °C |
| Dimensions (W × H × D) | ~240 × 550 × 266 mm |
| Weight | ~37 kg |
FAQ
FAQ
Q1: What motor power is the ATV61HD30N4 designed for?
The ATV61HD30N4 is designed for three‑phase motors with a rated power of 30 kW (40 HP).
Q2: What supply voltage and frequency does this drive require?
It operates on a three‑phase 380–480 V AC supply at 50 / 60 Hz.
Q3: What is the nominal output current of the ATV61HD30N4?
Nominal output current is approximately 56 A at 480 V and 66 A at 380 V.
Q4: What output frequency range can this drive provide?
The output frequency range is adjustable from about 0.1 Hz up to 599 Hz.
Q5: What control methods does the ATV61HD30N4 support?
It supports voltage/frequency (V/F) control and sensorless flux vector control for flexible motor speed and torque management.
Q6: Does this model include an EMC filter?
Yes — it includes an integrated Level 3 EMC filter for electromagnetic compatibility.
Q7: What are the physical dimensions and weight of this drive?
Typical dimensions are approximately 240 × 550 × 266 mm, and it weighs about 37 kg.
Q8: What protection rating and functions does the ATV61HD30N4 have?
The drive has an IP20 protection rating and includes built‑in protections such as overcurrent, overvoltage, undervoltage, and thermal protections.
