Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider ATV630D18N4 |
| Product Type | Variable Speed Drive |
| Series | Altivar Process ATV630 |
| Power Rating | 18.5 kW (25 HP) |
| Rated Voltage | 380–480 V AC, 3-phase |
| Rated Current | 39 A |
| Frequency Range | 0.5–500 Hz |
| Control Type | Sensorless flux vector control, V/F control |
| Overload Capacity | 120% of nominal current for 60 seconds |
| Communication Protocols | Modbus, Ethernet/IP, CANopen, Modbus TCP |
| Display | Integrated graphic display with navigation dial |
| Input Signal | 6 digital inputs, 3 analog inputs |
| Output Signal | 2 relay outputs, 2 analog outputs |
| Cooling Method | Forced air cooling with integrated fan |
| Protection Degree | IP21 (standard), IP54 (optional) |
| Ambient Operating Temperature | -10°C to +50°C (derating above 40°C) |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5%–95%, non-condensing |
| Altitude | Up to 1000 m without derating (up to 3000 m with derating) |
| Dimensions | 211 x 546 x 232 mm |
| Weight | 14.2 kg |
FAQ
FAQ
Q1: What is the function of the Schneider ATV630D18N4 Variable Speed Drive?
A1: It regulates the speed and torque of three-phase electric motors to improve energy efficiency and performance in industrial processes.
Q2: What is the power rating of this model?
A2: The ATV630D18N4 has a rated power of 18.5 kW (25 HP).
Q3: What control methods does it support?
A3: It supports both sensorless flux vector control and voltage/frequency (V/F) control.
Q4: What communication options are available?
A4: The drive supports Modbus, Ethernet/IP, CANopen, and Modbus TCP communication protocols.
Q5: What is the overload capacity of this drive?
A5: It can sustain 120% of its nominal current for 60 seconds.
Q6: What are its physical dimensions and weight?
A6: The dimensions are 211 x 546 x 232 mm, and it weighs is 14.2 kg.
Q7: What environments can this model operate in?
A7: It operates in ambient temperatures from -10°C to +50°C and humidity up to 95%, non-condensing.
Q8: Which industries typically use the ATV630D18N4?
A8: It is commonly used in HVAC, water treatment, manufacturing, and pumping applications.
