Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ATV930D22N4 |
| Brand | Schneider Electric |
| Product Series | Altivar Process ATV900 |
| Type | Variable Speed Drive (VSD) |
| Rated Supply Voltage | 380 – 480 V AC ±10% |
| Rated Power | 22 kW (30 HP) |
| Max Output Current | 45.7 A |
| Output Frequency Range | 0.1 to 599 Hz |
| Control Method | Sensorless or Sensor-Based Vector Control |
| Communication Interfaces | Modbus, Ethernet/IP, CANopen, etc. |
| Protection Rating | IP21 |
| Mounting Type | Vertical wall-mount |
| Cooling Method | Air-cooled |
| Operating Temperature | -15°C to +50°C (no derating) |
| Dimensions (W x H x D) | 211 x 545.9 x 235 mm |
| Weight | 14.3 kg |
FAQ
FAQ
Q1: What communication protocols are supported?
A1: ATV930D22N4 supports Modbus, Ethernet/IP, CANopen, Profibus DP, and Profinet.
Q2: Is it suitable for fan and pump control?
A2: Yes, it is specifically optimized for fan and pump applications with energy-saving and flow control functions.
Q3: Can it be installed outdoors?
A3: Its default protection level is IP21, so outdoor installation is not recommended unless enclosed in a protective cabinet.
Q4: Does this drive have a built-in braking unit?
A4: Yes, it includes a built-in braking chopper, but an external braking resistor is required.
Q5: Does it support multi-motor control?
A5: Yes, it supports sequential multi-motor control, making it ideal for parallel motor operations.
Q6: What software is used for configuration?
A6: Schneider’s SoMove or EcoStruxure Control Expert can be used for configuration and monitoring.
Q7: Does it support energy monitoring?
A7: Yes, it has a built-in energy metering function that monitors real-time power and energy consumption.
Q8: Does it require derating at high temperatures?
A8: Yes, derating is required above 50°C. Please refer to the product manual for derating curves.
