Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider ATV930U55N4 |
| Type | Variable Speed Drive |
| Function | Controls motor speed, enhances efficiency, provides smooth start and stop |
| Output Power | 55 kW |
| Input Voltage | 380-480 V AC |
| Input Frequency | 50/60 Hz |
| Output Frequency | 0-600 Hz |
| Control Mode | V/f Control, Vector Control, Speed Control |
| Speed Control | Supports PID control, manual/automatic modes |
| Communication | Modbus RTU, CANopen, Ethernet/IP |
| Efficiency | High-efficiency design, meets international standards |
| Display Screen | LCD screen showing voltage, current, frequency, etc. |
| Operating Temp | -10°C to +50°C |
| Storage Temp | -40°C to +70°C |
| Protection Rating | IP20 |
| Mounting Method | Panel or wall mount |
| Dimensions | 144 x 350 x 206mm |
| Weight | 4.7 kg |
| Compatibility | Compatible with various motors and system configurations |
FAQ
FAQ
Q1: What is the main function of the Schneider ATV930U55N4 Variable Speed Drive?
It is used to regulate motor speed and torque for smooth start-up, stopping, and energy-efficient operation.
Q2: What is the input voltage range?
The drive supports an input voltage range of 380-480 V AC.
Q3: What is the output frequency range?
The output frequency range is from 0 to 600 Hz.
Q4: What communication protocols does the drive support?
It supports Modbus RTU, CANopen, and Ethernet/IP communication protocols.
Q5: What is the operating temperature range?
The operating temperature range is from -10°C to +50°C.
Q6: Does the drive come with a display screen?
Yes, it has an LCD screen that displays voltage, current, frequency, and other real-time data.
Q7: How is the drive installed?
It can be installed in a panel or mounted on a wall, suitable for various industrial environments.
Q8: What are the dimensions and weight of the drive?
The dimensions are 144 x 350 x 206mm, and the weight is 4.7 kg.
